Victron Phoenix Inverter 48/250 230V VE.Direct IEC

Victron Phoenix 48/250 VE.Direct

The device converts 48 V DC from your battery into 230 V AC with a pure sine wave and uncompromising power quality that is also perfectly suited for sensitive electronic products. The efficiency of the Phoenix is outstanding and, thanks to ECO mode, one of the highest in its class. Via the VE.Direct communication port, using optional accessories, you can connect the device to a computer or smartphone and freely program several system parameters, such as the shutdown voltage and the restart voltage when the battery is empty! Many further configuration options, such as output frequency and output voltage, as well as a 2-pole alarm contact, are among the features of this voltage inverter.

Product features

• 200 watts continuous power at 230V 50Hz sine-wave voltage
• for 48V battery banks, works with all common battery types
• 230V AC power with a pure sine wave delivers perfect power quality
• freely programmable switch-on and switch-off thresholds
• freely adjustable output voltage in the range of 210 – 245V

Datasheet
